FTTH Aircraft Spiral fiber optic quick connector Assembly SC APC

FTTH Aircraft Spiral fiber optic quick connector Assembly SC APC,The SINDA Fast Connector series connectors are now available in FC, SC and LC variants, catering for 250um to 900um diameter single mode and multimode fiber types, including Multi-mode 62.5/125um and Multi-mode 50/125um. The single-mode versions are available with PC or APC ferrules.

Chat Now

Description

FTTH Aircraft Spiral fiber optic quick connector Assembly SC APC

Fast connector are factory pre-polished field-installable connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub and proprietary index matching gel combine to offer an immediate low loss termination to either single-mode or multimode optical fiber. Fast connectors are compatible with 250um and 900um optical fiber as well as 900um, 2mm, 3mm and drop cable cordage. All primary fiber types are supported. and each connector is color per industry standard requirments to aid in identification during and afger installation. Incorporated in device is an innovation. Translucent wedge enabling the use of a common VFI to provide a "pass/fail" signal once physical contact is achieved.

Features

This Fast Connectors feature a pre-stubbed factory-polished ferrule that couples to the fiber being terminated. Precision mechanical alignment insures low loss with a proprietary gel.
Connector Type: SC
Fiber Application: Singlemode, Multimode
Fiber Type: Simplex
Number of Fibers: 1
Maximum Cable Diameter (mm): 900um, 2mm, 3mm or 2X3mm Fiber Types
Connector Ferrule: Ceramic

Specifications

Name	Spe.	Remarks
Fiber type	Single mode or Multi mode	Consistent with ROHS,IEC
Applicable for	Indoor or Outdoor FTTH
Cable diameter	2*3mm,φ3.0mm
Diameter of Cermic core	2.499±0.002mm
Concentricity of Ceramic core	≦0.5um
Material of plastic parts	PBT(Main-body)；PEI(Inner-core);Dust Cap(PE)
Spring material	304

Applications

Router
Set top Box
Wireless Device
Television Equipment

Quality Certification
